Model NO.	UHD
System Operating Platform	WIN XP
Display Type	LED Video Display
Application	Conference
IP Rating	IP40
Certification	CE, RoHS, CCC, ETL
Gray Scale	16 Bit
Warranty	2 Years
Brightness	600-800 CD/Sqm
Contrast Ratio	4000:1
Operating Voltage	110~220V AC,50/60Hz
Usage	Indoor
Expected Lifetime	More Than 100,000hrs
Driver IC	Mbi5124
Light	Nationstar
Material	Die-Casting Aluminum
Transport Package	Flight Case/Plywood Case
Specification	150mm*168mm
Trademark	Bako visIon
Origin	China
HS Code	8528591090
Production Capacity	8000sqm Per Month

Product Description

Front-access P1.2 P1.5 Fine Pitch LED video WallPanel HD LED Display for Traffic centre
Fine Pitch Display Description

Slim &Lightweight, only 6kg
16:9 High Definition & High Resolution
Full Front Maintenance

Fine Pitch Display Parameters:

Pixel Pitch	UHD-1.2	UHD-1.5	UHD-1.8	UHD-2.3
LED Type	SMD black LED
Module Size	150mm*168mm
Cabinet Size	600mm*337mm
Module Resolution	120*135	96*108	80*90	64*72
Cabinet Weight	6kg
Cabinet Material	Die-Casting Aluminum
Gray Scale	16bit
Contrast Ratio	4000:1
Brightness	600-800cd/Sqm
View Angle(H/V)	160°/140°
Refresh Rate	1920Hz
IP Rating	IP40/IP21
Optimal Viewing Distance	1.5m	1.9m	2.3m	2.9m
Average Power Consumption	300 W/Square meter
Maximum Power Consumption	600W/Square meter
Operating voltage	110~220V AC,50/60HZ

Fine Pitch Display Features:

Details:

Front-Access P1.2 P1.5 Fine Pitch LED Video Wallpanel HD LED Display for Traffic Centre

Cases Pictures:

Company Introduction:
Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005,a world class manufacturer of technologically advanced LED displays,it is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.

BAKO VISION product lines have include I/O rantal,I/O fixed, UHD fine pitch, transparent screen,advertising poster,foldable screen… meanwhile, based on our experienced R&D team,and comprehensive management , we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.

FAQ

Q1:How to choose a proper led screen for your need?

A:You just need to think of 3 simple questions when you choose a led screen by yourself.1.Will you use it indoor or outdoor?2.Is it for rental use(need to be moved from one place to another place very often) or for fixed installation(to be installed in one place forever)?3.what is the appoximate size of the led screen you would like to purchase?Q2:Which pixel pitch should i choose?

A:There are many different pixel pitch from 1.667--20,25,30mm, there is a roughly principle-usually small pixel(1.667mm-10mm) used for indoor led screen, bigger pixel (10mm-30mm) used for outdoor led screen(for example high way huge advertisement).

Q3:Which control system should i choose?

A:There is both synchronous and asynchronous control system for led screen on the market,for big size led screen(usually more than 20sqm) need to use synchronous control system,below 20sqm it's up to you to use syn or asyn.But asyn control system's refresh rate is much lower than sync control system and for asyn control system, you can choose to use wifi,3G,4G etc wireless control.Q4:How to order from you compamy?

A:You can both place order to us by online or to our company directly offline, before place order welcome to contact us for confirmation.

Q5:How to pay?

A:We accept L/C, T/T bank, or paypal or westerunion.Q6:How to ship?

A:It is optional and we respect customer's choice. You can choose to ship by air cargo, by DHL(Fedex,UPS etc) internation express company, or by sea according to your goods weight and volume and the delivery time you need.Q7:How to install it after i received it?

A:We will offer you the drawing to guide you for installation, we could also offer steel drawing, software set up drawing or photo or send our engineer fly to you for help if needed.
